Attaches two 26V batteries directly to the back of the ARRI Alexa LF, 65, and SXT cameras. Prioritized 2pin DC input to support block batteries with hot-swap backup and OLED screen for voltage information. Includes two regulated 15V P-Tap ports enabling Dionic 26V batteries to be swapped without the need to disconnect P--TAP powered accessory cables.
Shark Fin plate enables hot swapping between 26V batteries and also provide continued power when swapping out block-style batteries such as the Anton/Bauer VCLX.
Also known as Wooden Camera - 26V Sharkfin Gold Mount (Alexa LF, 65, SXT) - SKU 273100.
Compatibility
Anton Bauer Plate Shark Fin 26VGld Mt Plus attach 2x26V batteries to ARRI Alexa LF & 65 & SXT cameras
Key Features
- Wooden Camera / Anton Bauer 26V Gold Mount Plus Shar Fin Plate enables (2) Dionic 26V batteries to power an Alexa LF, 65, or SXT Camera.
- Shark Fin Plate attaches to the back of the ARRI Alexa LF, 65, or SXT cameras through battery contacts without cables.
- Internal circuit board prioritizes the 2pin Fischer DC Input, allowing 24V block batteries to be used first, leaving the on-board batteries fully charged.
- Hot swapping Dionic 26V batteries as well as battery sources such as a Anton/Bauer VCLX block battery standard.
- OLED screen provides voltage data, battery capacity, and active source information.
- Two P-TAPS provide regulated 15V power.
- Plate includes a ""digital reset"" through the OLED if current thresholds are exceeded and cuts power to the P-TAPs.
